22Ah 12S1P 44.4V Smart Battery

Category Tag
Nominal Voltage 44.4V
Typical Capacity 22000mAh
Configurations 12S1P
Cell Type Li-ion Polymer
Positive Material Pure Lithium Cobalt
Energy 976.8Wh
Max Discharge Rate 25C
Max Discharge Current 550A
Charging Time Approx 3.0 Hours (0.5C)
Standard Charge Current 4400mA (0.2C)
Max Charge Current 220A (10C)
Discharge Connector  QS9L
Charging (Balancing) Connector JST-XHP-16PIN
Operating Temperature Range -20°C ~ 60℃
Battery Size 235L x 172D x 107W mm
Battery Weight 6000g

Smart Battery 22000mAh 12S1P 44.4V

Agricultural Drone Battery Custom Solutions


SPP Battery specializes in customization, ODM/OEM of agricultural drone batteries.

We design and manufacture customized batteries or cells according to the specific requirements from our customers,

including BMS customization, for professional applications of agricultural drones or industrial class ones.


Customized BMS


SPP Battery’s BMS is mainly designed for intelligent flight batteries,

which adopts an industrial-grade ARM-32 bit processor and matches a high-precision AFE front-end acquisition chip.

This kind of BMS provides security protection, data statistics, and intelligent management for smart drone batteries with specifications for 12S1P.


BMS Features List

  • Charge management

Overcharge protection

Balancing charging

  • Discharge management

Over-discharge protection

Over-current protection

High-temperature protection

Low-temperature protection

  • Other management

Short circuit protection

Smart storage

High precision SOC indicates

Battery health management

Communication protocol management

Data logging


Applications of Drone Battery


SPP drone batteries are widely used in agricultural spraying, industrial patrol, forest fire fighting, construction monitoring, cargo transport, aerial photography, surveying & mapping, it’s also the best choice for DIY unmanned drones.
